SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21%

10 kilogramos
MOQ
negotiable
Precio
SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21%
Caracteristicas Galería Descripción de producto Pida una cita
Caracteristicas
Especificaciones
Forma: Esfera
Densidad aparente: ≥ 0,75 g/ml
Tamaño: 1.6-2.5m m, 3.0-5.0m m
Punto de rocío: ≤ -73 ℃
Fuerza compresiva: 100n
Adsorción estática del agua: ≥ 21%
Información básica
Lugar de origen: Shanxi, China
Nombre de la marca: Xi'an Lvneng
Certificación: ISO9001:2008
Número de modelo: tamiz molecular 3A
Pago y Envío Términos
Detalles de empaquetado: 1. tambor 25KG/Carton, 2. caja 25KG/Carton, 3. tambor del hierro 150KG/Sealed
Tiempo de entrega: 3-15 días laborables
Condiciones de pago: Unión Occidental, T/T, L/C
Capacidad de la fuente: 100 toneladas por mes
Descripción de producto
3A Zeolite Molecular Sieve Desiccant For Ethylene Propylene Natural Gas Desiccation
Product Overview

The 3A molecular sieve features a large specific surface area with uniform particle size, smooth appearance, and high mechanical strength. It exhibits strong dilution capabilities, no swelling after water absorption, no cracking, maintains original state, is odorless, and insoluble in water and ethanol.

In industrial production, it's used for drying gases including air, hydrogen, oxygen, nitrogen, and argon. Typically, two adsorption dryers are connected in parallel - one operates while the other regenerates, ensuring continuous equipment operation. The dryer works at 8-12°C and regenerates by flushing under heating to 350°C. Molecular sieves also provide good catalytic effects for certain organic gas reactions.

3A molecular sieve is an alkali metal aluminosilicate, also known as 3A zeolite molecular sieve. It primarily adsorbs water and does not adsorb any molecules with diameters larger than 3Å, making it essential for deep drying, refining, and polymerization of gas and liquid phases in petroleum and chemical industries.

SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21% 0 SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21% 1 SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21% 2
Technical Specifications
Item Unit 8×12 Mesh 4×8 Mesh
Bead Size mm 1.6-2.5 3.0-5.0
Bulk Density g/ml ≥ 0.75 0.68
Equilibrium Water Capacity @ 25°C wt% ≥ 21 21
Equilibrium Ethylene Capacity mg/g ≤ 3.0 3.0
Heat of Adsorption BTU/lb of H₂O 1800 1800
Crush Strength (Point Contact) N ≥ 35 100
Variation Coefficient - 0.3 0.3
Attrition Rate wt% ≤ 0.1 0.1
Size Qualification % ≥ 98 98
Package Moisture wt% ≤ 1.5 1.5
Packaging
SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21% 3 SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21% 4 SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21% 5
Factory Overview
SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21% 6 SGS & REACH Certified 3A Zeolite Molecular Sieve Desiccant with Dew Point ≤ -73℃ and Static Water Adsorption ≥21% 7
Usage Guidelines
  • The product cannot be exposed in open air and should be stored in dry conditions with air-proof bags
  • It should be regenerated after a certain period of adsorption. The appropriate regeneration temperature should be below 350°C
Frequently Asked Questions
Q: Could we send a free sample for reference?
A: Yes, of course.
Q: What about the price and MOQ?
A: We promise a competitive price with top quality, and accept both mass and small quantity orders.
Q: What is the lead time?
A: Within 15 days after receiving payment.
Q: Payment term?
A: 100% TT in advance, or 30% TT deposit with balance before shipment.
Q: How to solve problems after sales?
A: Take photos of the problems. After confirmation, we will provide a satisfying solution within 3 days.

For more information please contact us. It's our pleasure to serve you.
